EMCView EMC Pre-Compliance Software License
The Tekbox EMC compliance software EMCview for PCs is a user-friendly EMC pre-compliance testing of radiated and conducted emissions. It is a perfect complement for automated testing using our LISNs and TEM Cells.
A built-in amplitude correction enables correction and conversion coefficients for cables, amplifiers, attenuators, LISNs, TEM cells, antennas, RF current probes, striplines and capacitive coupling clamps.
There is no need for a time-consuming setup. The SW is ready for measurements straight after installation. All emission related CISPR-xx (EN550xx) measurements and a few automotive manufacturer standards are pre-configured in corresponding project files.
The graph supports two complete measurement runs such as for example Average / Quasi-Peak or Peak / Quasi Peak and alternatively a fast Quasi-Peak scan of critical peaks.
Furthermore, EMCview together with our GPS receiver can be used to carry out RF-coverage measurements. An export feature creates KML files which link the result to google maps.
EMCView currently supports the following spectrum analyzers
- Rigol (DSA and RSA)
- Siglent (SSA/SSA plus and SVA)
- R&S (FPC and FPH)
- OWON XSA and HSA
- Teledyne Test Tools T3SA series
- BK Precision 2683 series
Features
- numerous pre-configured project files for CISPR-xx (EN550xx) emission measurements
- Graph supports two complete measurement runs, same as in test house
- fast Quasi-Peak scan of critical peaks, immune to frequency drift of the selected peaks
- configurable limit lines and segment files
- configurable correction files for cable, LISN, amplifier, antenna etc.
- configurable margins for the identification and selection of critical peaks
- supports import and overlaying of reference measurements for comparison purpose
- linear or logarithmic frequency axis
- automatic creation of test reports
- many import/export-functions
- RF coverage measurements
- tracking generator control for immunity testing
Applications
- in house measurement of EMC behavior during product design phase
- EMC training in lab, school and university
- pre-compliance test of products before submitting it to the test house
- test cost reduction
- reduced time to market
EMCView Manual
EMCView Version 7.06 download, can be used for measurements up to 10MHz without license file
EMCView FAQ
Free dB Calculator
Application Note: Conducted noise measurements using the TBOH01 and EMCView
Application Note: Conducted noise measurements using the TBLC08 and EMCView
Application Note: RF current probes with EMCView
Application Note: Conversion of common mode currents to radiated emissions on cables
Conversion files for the AN conversion of common mode currents to radiated emissions on cables
Application Note: Amplitude units and conversion in EMCView
Application Note: Antenna factors in EMCView
Application Note: Immunity testing example using Tekbox TEM Cells
